Precision & Miniature Pressure Sensors

Operating Temperature Range

PMC-STS, Inc. transducers are designed to operate over the temperature range appropriate for the application. Special designs are available for cryogenic temperatures from -320°F to 300°F (-196°C to 150°C). Most types are suitable for the traditional aviation range of -65°F to 300°F (-54°C to 150°C). Storage, operating, and compensated temperature can be customized.

Input/Output

Passive transducers with ratiometric input/output of 1Omv/V are available in most configurations. Amplified analog outputs up to 1OVdc or 4-20mA from supply voltages of from 5Vdc to 32Vdc. Digital outputs including CANBus, RS485 and RS232.

Special Features

PMC-STS, Inc. transducers are designed for operation in high vibration applications of 50g or more and tested to more than 1 million cycles. Testing follows Mil Std 810 methods.
